ASTM A285 Gr.C ASME SA285 Gr.C boiler and pressure vessel steel A285 grade C plate

A285 Gr.C pressure vessel steel Description

A285Gr.C boiler and pressure vessel steel belongs to medium and low-strength carbon steel plate. The grade A285 Cr.C is equivalent to China's GB713 boiler pressure vessel steel plate Q245R. ASTM A285 Grade C boiler vessel plate is used for welding pressure vessel equipment. Ordinary carbon steel, with good welding performance, can meet the fusion welding requirements of pressure vessel equipment, ASTM A285 Gr.C boiler vessel plate is widely used in boilers, storage tanks, heat exchangers, manufacturing reactors, separators, spherical tanks, oil and gas Tanks, nuclear reactor pressure shells, high-pressure water pipes, turbine shells and other equipment. In order to ensure its mechanical properties, the thickness of ASTM A285 Grade C boiler vessel plate is limited to 50mm. ASTM A285 boiler vessel steel contains 3 grades: Grade A, Grade B, and Grade C.

A285 Grade C carbon steel plate under the ASTM A285/A285M standard, the tensile strength of A285Cr.C boiler pressure vessel steel is 380-515MPa, and the yield strength is ≥205MPa. Therefore, A285Cr.C steel plate has very high strength, toughness, fatigue resistance, and Impact and corrosion resistance. BBN Steel can provide various sizes of A285 Grade C boiler and pressure vessel steel, usually delivered in the state of normalizing or hot rolling, and provides various deep processing services such as cutting, welding, bending, drilling, etc., to meet the needs of different customers need.

ASTM A285 covers 3 steel grades - A285 Grade A, A285 Grade B, A285 Grade C. ASTM A285 boiler steel plate pressure vessel steel sheet has good weld-ability for fusion weld need for pressure vessel equipment.

A285 Gr.C pressure vessel steel Datasheet

Thickness: 8mm-150mm

Length: 1m-14m or according to customer's special request

width: 1000mm-4000mm

Delivery condition: Hot rolled, controlled rolled, or normalized

Surface: Black Finish, Oiled, Shot Blasted, Spray Paint, Coated,Galvanized Or as Your Request

Cutting service: Large steel plate cut to flat plate sizes, or cut to any size by drawing

Deep processing: After cutting large plate into the general sizes by drawing, milling and grinding, and make angles, polishing, and make special part

Package: tied up with steel strips and wrapped with water proof paper

A285 Gr.C pressure vessel steel Chemical composition

A285 Gr.C pressure vessel steel Mechanical Properties

Equivalent Grade of A285 Gr.C pressure vessel steel
