S20C Round Steel Bar JIS S20C Carbon Steel Round Bar Rod

S20C Round Bar Description

S20C Round Steel Bar is a high-quality carbon structural steel according to the Japanese JIS standard. The strength of S20C is slightly higher than that of 15# steel, with little quenching and no tempering brittleness. Cold deformation has high plasticity and S20C Round Steel is generally used for processing such as bending, rolling, bending edges, and hammer arches. The welding performance of electric arc welding and contact welding is good, and the thickness is small during gas welding. Cracks are prone to occur on parts with strict external requirements or complex shapes. The cold drawn or normalized state has better machinability than the annealed state, and S20C is used to manufacture parts with low stress and high toughness requirements.

S20C Low-Carbon Round Bar is suitable for manufacturing mechanical parts and structural components, such as bolts, nuts, screws, bearings, wheel hubs, gears, etc. After carburizing, quenching, and tempering treatment, the carburizing and quenching hardness is 56-60HRC, which can obtain molds with high external hardness and good core toughness.

The equivalent materials for Japanese JIS designation: S20C/S22C round bars are Chinese GB/JB designation: 20, American AISI designation: 1020, German DIN steel designation: CK22/C22, German DIN material designation: 1.0402, Taiwan CNS designation: S20C, UK BS designation: IC22, France AFNOR designation: CC20, Italy UNI designation: C20/C21.

S20C Round Bar Datasheet

S20C carbon steel delivery specifications:

Cold-rolled S20C steel strip specifications: 0.2~2.0mm;

Cold rolled S20C steel plate specifications: 0.5~4.0mm;

Hot rolled S20C steel plate specifications: 2.0~300mm;

Cold drawn S20C round bar specifications: Φ4.0~60mm;

Hot rolled S20C round bar specifications: Φ16~350mm.

S20C Round Bar Chemical composition

S20C Round Bar Mechanical Properties

Equivalent Grade of S20C Round Bar
