S355K2W Weathering Resistant Steel EN 10025 S355K2W Corten Steel Plate

Description: S355K2W weathering steel under EN 10025-5 European standard,S355K2W steel is an improved weathering structural steel of 60-120mm. S355K2W atmospheric corrosion resistant steel is added with certain alloying elements, such as phosphorus, copper, chromium, ...

If the standard size steel materials can not meet your demands, We aslo supply S355K2W Steel processing service. you can find one-stop solution for various customized steel processing requirements: Large vessels, structural parts, semi-products, components, manufacturing supporting ...

Processing Service: Cutting, Welding, Drilling, Rolling, Bending, Forming, Grinding, Stamping and so on machining

E-mail: [email protected]

Whatsapp: +86-15690878691

Chat Online Leave a Message

S355K2W Steel Description

S355K2W weathering steel under EN 10025-5 European standard, S355K2W steel is an improved weathering structural steel of 60-120mm. S355K2W atmospheric corrosion resistant steel is added with certain alloying elements, such as phosphorus, copper, chromium, nickel, molybdenum, etc., to form an automatic protective oxide layer on the metal surface under the influence of climatic conditions to enhance its atmospheric corrosion resistance. The atmospheric corrosion resistance of weathering steel is 2-8 times that of ordinary carbon steel, and it has good mechanical properties, welding properties, etc., and the longer the time, the more obvious the corrosion resistance effect.

BBN Steel can provide S355K2W steel plate specification range: thickness 8-700mm, width 1500-4020mm, length 4000mm-17000mm, single weight up to 30.00 tons. Larger steel plates are also available upon request. Available for flaw detection requirements, Z15-Z35 thickness direction performance requirements, high strength and high toughness requirements and other steel plates.

S355K2W weathering steel plates are mainly used for steel structures exposed to the atmosphere for a long time, such as vehicles, towers, bridges, railways, photovoltaics, and high-speed projects. It is used to manufacture structural parts such as containers, railway vehicles, oil derricks, seaport buildings, oil production platforms and containers containing hydrogen sulfide corrosive medium in chemical and petroleum equipment.

S355K2W Weathering Resistant Steel and Mechanical Properties, Chemical Element, Cross Reference, Datasheet.

Heat treated : 1193°C - 1349°C

S355K2W Steel Datasheet

Product	Weathering steel plate
Standard	ASTM, AISI, DIN, EN, BS, SUS, JIS
Grade	S355K2W
Thickness	3-100mm or as required
Width	200-3000mm or as required
Length	1000-6000mm or as required
Container Size	20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) 40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High)
Application	steel plate are widely used in Automobile, Bridges, Buildings Machinery, Pressure vessel industries,Engineering construction

S355K2W Steel Chemical composition

C ≤	Si ≤	Mn ≤	P ≤	S ≤	Cr	Ni
0.16	0.50	0.50-1.50	0.030	0.030	0.40-0.80	≤0.65
Mo	Al	Cu	Nb	Ti	V	Ce
		0.25-0.55
N	Co	Pb	B	Other

S355K2W Steel Mechanical Properties

EN 10025 S355K2W weathering steel plate,“S” means S355K2W grade could be used in structural steel projects, 355 is the min yield strength. K2 standard for the impact degree and energy in -20 temperature. W” means that the mainly different in their carbon and phosphorus contents and availability.

Yield R_p0.2 (MPa)	Tensile R_m (MPa)	Impact KV/Ku (J)	Elongation A (%)	Reduction in cross section on fracture Z (%)	As-Heat-Treated Condition	Brinell hardness (HBW)
928 (≥)	522 (≥)	11	43	14	Solution and Aging, Annealing, Ausaging, Q+T,etc	121

Equivalent Grade of S355K2W Steel

Type	Steel Grade	Standard	Country	Application
Weather Resistant Steel	1.8967	EN	European	Mainly used for construction of tanks, containers, bridges, frame structures, vehicles, etc
Weather Resistant Steel	S355K2G2W	EN	European	Ideal for welding, riveting or bolting in construction applications, primarily for bridges and buildings.
Weather Resistant Steel	E36WB4	AFNOR	France	Mainly used for architecture, smokestacks, fabrication, freight wagons, silos, pylons etc.
Weather Resistant Steel	A709Gr.50W	ASTM	USA	Mainly used for architecture, smokestacks, fabrication, freight wagons, silos, pylons etc.
