SSAB HARDOX450 Abrasion Resistant Plate HARDOX450 Wear-Resistant Steel

FOB Reference Price: Get Latest Price

Description: HARDOX450 Abrasion Resistant Steel Plate has good cold bendability and weldability. The average Brinell hardness of Hardox450 steel plate has reached 450HB, which can better resist dents and wear, and has a longer wear life. The typical yield strength of ...

Processing Service: Cutting, Welding, Drilling, Rolling, Bending, Forming, Grinding, Stamping and so on machining

Available Size: Thickness: 4-100mm, Width: 900-4700mm, Length: 5000-18000mm

E-mail: [email protected]

Whatsapp: +86-15690878691

HARDOX450 Abrasion Resistant Steel Plate Description

HARDOX450 Abrasion Resistant Steel Plate has good cold bendability and weldability. The average Brinell hardness of Hardox450 steel plate has reached 450HB, which can better resist dents and wear, and has a longer wear life. The typical yield strength of the material is about 1200MPa. HARDOX450 wear-resistant plate can be used in dump truck compartments, containers, crushing Machine, sieve plate, feeder, feed hopper, elevator, blade, conveyor, bucket, blade, gear, sprocket, etc.

SSAB HARDOX450 Wear-Resistant Steel Plate is an ultra-high-strength wear-resistant steel alloyed with manganese and chromium. It has high strength, high hardness, good toughness, good hardenability, no temper brittleness, excellent fatigue resistance and excellent casting process performance, etc. It is a new generation of widely used superhard materials. HARDERX450 is mainly used in the manufacturing of high wear and consumption conditions, such as metal processing, mining machinery, construction machinery, agricultural machinery and other equipment parts.

HARDOX450 Wear-Resistant Steel Plate belongs to high-strength toughness cold work die steel, which has good comprehensive mechanical properties and processing performance. When used in quenched and tempered state, it can obtain higher hardness, red hardness and toughness; when used in annealed state, it can maintain good toughness; when used in normalized state, it can refine grains and eliminate structural defects, and obtain the best Comprehensive mechanical properties. This product is mainly used in the manufacture of dies and dies that are subjected to large impact loads. In addition, it is also used to make various cold extrusion dies, and can also be used to make measuring tools, samples, cutting tools and wire drawing dies.

HARDOX450 Abrasion Resistant Steel Plate Datasheet

Thickness:  3mm~130mm,
Width: 1000mm~3200mm,
Length: 2000mm~12000mm or as required
Thickness tolerance: ±0.1mm
Standard: GB/T24186
Technique:Hot rolled
Surface Treatment: Clean, blasting and painting according to customer requirement

HARDOX450 Abrasion Resistant Steel Plate Chemical composition

Grade C Si Mn P S Cr Ni Mo B
Hardox450 ≤0.25 ≤0.70 ≤1.60 ≤0.025 ≤0.010 ≤0.50 ≤0.25 ≤0.25 ≤0.004
Hardox500 ≤0.29 ≤0.70 ≤1.60 ≤0.025 ≤0.010 ≤1.00 ≤1.00 ≤0.60 ≤0.004
Hardox550 ≤0.31 ≤0.70 ≤1.60 ≤0.025 ≤0.010 ≤1.00 ≤1.00 ≤0.80 ≤0.004
Hardox600 ≤0.33 ≤0.70 ≤1.60 ≤0.025 ≤0.010 ≤1.00 ≤1.00 ≤0.90 ≤0.004

HARDOX450 Abrasion Resistant Steel Plate Mechanical Properties

Grade Y.S(MPa) T.S(MPa) EL.A5(%) HBW T AKVJ
Hardox450 ≥1350 ≥1550 ≥11 430-480 -40 ≥35
Hardox500 ≥1550 ≥1750 ≥11 480-530 -40 ≥30
Hardox550 ≥1550 ≥1750 ≥11 530-580 -40 ≥35
Hardox600 ≥1750 ≥1750 ≥11 580-630 -40 ≥40

Carbon equivalent CET (℅) [CET=C+(Mn+Mo)/10+(Cr+Cu)/20+Ni/40]: 0.35

Carbon equivalent CEV (℅) [CEV=C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15]: 0.53

Equivalent Grade of HARDOX450 Abrasion Resistant Steel Plate

Steel Grade GB/T24186(China) Thyssenkrupp JFE (JAPAN) Ruukki
HARDOX450 NM450 XAR450   Raex 450
