RAEX400 Wear-Resistant Steel RAEX400 Abrasion Resistant plate

RAEX400 Wear-Resistant Plate Description

RAEX400 Wear-Resistant Steel Plate produced in Finland(RUUKKI). RAEX400 steel is a hardened wear-resistant steel with an average grade of 400HBW (Brinell hardness). The microstructure of this wear-resistant steel is a martensitic structure, which can ensure the high hardness and tensile hardness of the steel plate. The hardness of RAEX400 steel is 2.5 times that of S355 structural steel. High hardness and tensile strength give RAEX 400 high wear resistance in rolling contact. Despite its high hardness and strength, RAEX 400 can be formed by free bending or hemming and has good weldability. Due to its ability to withstand rolling contact and high surface pressure wear, this hardened steel can be used to significantly reduce the costs associated with wear and wear of structural components.

Main application of RAEX400 Abrasion Resistant plate: Widely used in crushers, crushers, dump truck compartments, containers, sieve plates, feeders, feed hoppers, elevators, blades, conveyors, buckets, blades, gears , sprockets, liners, bolt-on blades, wear strips, chutes, knives, hammers, etc.

RAEX400 Wear-Resistant Plate Datasheet

Thickness:  3mm~130mm,
Width: 1000mm~3200mm,
Length: 2000mm~12000mm or as required
Thickness tolerance: ±0.1mm
Standard: RUUKKI
Technique:Hot rolled
Surface Treatment: Clean, blasting and painting according to customer requirement

RAEX400 Wear-Resistant Plate Chemical composition

RAEX400 Wear-Resistant Plate Mechanical Properties

Equivalent Grade of RAEX400 Wear-Resistant Plate
