XAR400 Wear Resistant Plate XAR400 Abrasion Resistant Sheet Plates

XAR400 Wear Resistant Plate Description

XAR400 (1.8714) wear-resistant plate is a special structural steel with high wear resistance. The average hardness of the wear-resistant special mechanism steel is 400HB. XAR400 wear-resistant steel plate has high toughness, excellent bending performance and welding performance. After quenching or quenching and tempering, it has a good martensite-bainite microstructure. The grades of wear-resistant steel plates of the same grade are NM400/AR400/WNM400/HAROX400.

XAR400 wear-resistant steel plate belongs to German ThyssenKrupp XAR series steel, which is an important high-tech wear-resistant steel material. The thickness of the steel plate produced can reach 100m. Widely used in loading and cutting machinery, engineering machinery, agricultural machinery, mining machinery, metallurgy, electric power and other fields. The average hardness value of XAR400 wear-resistant special structural steel has high hardness and good toughness. The structure built with this steel is stronger and lighter, and can withstand impact loads.

The main application scope of XAR400 Abrasion Resistant Steel Plate:

Building machinery: cement pusher tooth plate, concrete mixing building, mixer liner, dust collector liner, brick machine mold plate, etc.

Construction machinery: loader, bulldozer, excavator bucket plate, side edge plate, bucket bottom plate, blade, rotary drilling rig drill pipe, etc.

XAR400 Wear Resistant Plate Datasheet

Thickness:  3mm~130mm,
Width: 1000mm~3200mm,
Length: 2000mm~12000mm or as required
Thickness tolerance: ±0.1mm
Standard: THYSSENKRUPP
Technique:Hot rolled
Surface Treatment: Clean, blasting and painting according to customer requirement

XAR400 Wear Resistant Plate Chemical composition

XAR400 Wear Resistant Plate Mechanical Properties

Carbon equivalent CET (℅) [CET=C+(Mn+Mo)/10+(Cr+Cu)/20+Ni/40]: 0.32

Carbon equivalent CEV (℅) [CEV=C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15]: 0.48

Equivalent Grade of XAR400 Wear Resistant Plate
