EN10083-3 51CrV4 alloy steel plate 51crv4 spring steel

Description: 51CrV4 alloy steel is a high-strength quenched and tempered steel suitable for quenched and tempered springs. It is an alloy steel with high strength and good rust resistance. 51CrV4 steel is composed of different amounts of elements, mainly including: ch...

Processing Service: Cutting, Welding, Drilling, Rolling, Bending, Forming, Grinding, Stamping and so on machining

Available Size: Thickness: 4-100mm, Width: 900-4700mm, Length: 5000-18000mm

E-mail: [email protected]

Whatsapp: +86-15690878691

Chat Online Leave a Message

51CrV4 Alloy Steel Description

51CrV4 alloy steel is a high-strength quenched and tempered steel suitable for quenched and tempered springs. It is an alloy steel with high strength and good rust resistance. 51CrV4 steel is composed of different amounts of elements, mainly including: chromium, vanadium, Titanium, chromium, silicon, manganese and molybdenum etc. 51CrV4 alloy steel is mainly used to manufacture bearing parts, springs, steel wires and other precision steel parts. It is characterized by high strength, easy processing, not easy to deform, and strong rust resistance, and has a wide range of application values.

The machining performance of EN10083-3 51CrV4 alloy steel mainly refers to its cutting performance. Its cutting performance is higher than that of ordinary carbon steel, but it is also lower than that of stainless steel. Its cutting performance is mainly affected by its heat treatment state. Therefore, When processing 51CrV4 (50CrV4) alloy steel, attention should be paid to its heat treatment state, and it is best to use a lower cutting speed to produce better cutting performance.

51CrV4 low-alloy spring steel is a high strength quenched and tempered steel suitable for quenched and tempered springs. It can be used as a high-load important spring with a large cross-section and a valve spring, piston spring, and safety valve spring with an operating temperature of <300°C. 51CrV4 is equivalent to China's 50CrV or 50CrVA.

51CrV4 Alloy Steel Datasheet

Thickness: 1.2mm - 250mm
Width: 900mm - 4200mm
Length: 5000mm - 18000mm or as your request
Technique: Hot Rolled / Forged / Cold Drawn
Certificate: API, ISO, SGS, BV, CE etc
Quality: MTC will be provided with goods, third part inspection is acceptable

51CrV4 Alloy Steel Chemical composition

Grade	C	Si	Mn	P	S	Cr	V
51CrV4	0.47-0.55	0.40	0.7-1.1	0.025	0.025	0.9-1.2	0.10-0.25

51CrV4 Alloy Steel Mechanical Properties

t ≤ 8mm			8mm < t ≤ 20mm			20mm < t ≤ 60mm			60mm <t ≤ 100mm			100 < t ≤ 160mm
Re min	Rm	A min	Re min	Rm	A min	Re min	Rm	A min	Re min	Rm	A min	Re min	Rm	A min
MPa	MPa	%	MPa	MPa	%	MPa	MPa	%	MPa	MPa	%	MPa	MPa	%
900	1100-1300	9	800	1000 - 1200	10	700	900-1100	12	650	850-1000	13	600	800-950	13

Equivalent Grade of 51CrV4 Alloy Steel

As a leading factory and exporter of 51CrV4 quenched and tempered steel plates, we supply 51CrV4 steel sheets, 51CrV4 plates thickness up to 160mm. EN10083-3 51CrV4 alloy steel sheets are delivered as rolled, soft annealed normalized or quench and tempered. It is used for automotive and aircraft components with high toughness such as axles, axle journals, turbine parts, turbine rotors. If you are interested in our 51CrV4 plate price, welcome to contact us.
