S355J0WP weathering steel plate, EN10025 S355J0WP High Strength Steel

Description: S355J0WP weathering steel plate under the European standard EN10025-5:2004. S355J0WP steel is also named atmospheric corrosion-resistant steel, it is a low-alloy steel series between ordinary steel and stainless steel. S355J0WP weathering steel has the ch...

If the standard size steel materials can not meet your demands, We aslo supply S355J0WP Steel processing service. you can find one-stop solution for various customized steel processing requirements: Large vessels, structural parts, semi-products, components, manufacturing supporting ...

Processing Service: Cutting, Welding, Drilling, Rolling, Bending, Forming, Grinding, Stamping and so on machining

E-mail: [email protected]

Whatsapp: +86-15690878691

Chat Online Leave a Message

S355J0WP Steel Description

S355J0WP weathering steel plate under the European standard EN10025. S355J0WP steel is also named atmospheric corrosion-resistant steel, it is a low-alloy steel series between ordinary steel and stainless steel. S355J0WP Weathering steel is made of ordinary carbon steel with a small amount of corrosion-resistant elements such as copper and nickel. The atmospheric corrosion resistance of weathering steel is - 2-8 times that of ordinary carbon steel, and has the characteristics of high-quality steel such as toughness, plasticity, forming, welding and cutting, abrasion, high temperature, and fatigue resistance. At the same time, S355J0WP weathering steel has the characteristics of rust resistance, corrosion resistance and longevity of components, thinning and consumption reduction, labor saving and energy saving.

S355J0WP weathering structural steel plate is used for bridges, ships, power station equipment, hoisting and transporting machinery, machinery manufacturing and other engineering and welded structural parts that bear higher loads.

Under the European standard EN10025, we also have other grades: S235J2W, S235J0W, S355J0WP, S355J2WP, S355J0W, S355J2W, S355K2W.

The grade of S355J0WP indicates:

"S": indicates structural steel;

"355" indicates that the minimum yield strength of thickness ≤ 16mm is 355, expressed in MPa;

"J" : Quality identification representing the relevant impact energy value;

"0": means 0°C impact test;

"W" indicates that the steel is resistant to atmospheric corrosion;

"P": Indicates high phosphorus content grade.

S355J0WP Weathering Carbon Steel and Mechanical Properties, Chemical Element, Cross Reference, Datasheet.

Heat treated : 1899°C - 1858°C

S355J0WP Steel Datasheet

Product	Weathering steel plate
Standard	EN10155
Grade	S355J0WP
Thickness	1-200mm
Width	1500mm- 2200mm or customized
Length	4000mm- 12000mm or customized
Container Size	20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) 40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High)
Application	steel plate are widely used in shipping building,engineer construction, mechanical manufacturing

S355J0WP Steel Chemical composition

We have the chemical analysis of S355J0WP Weathering Steel available for you below. The material S355J0WP High Strength Steel contains Carbon, Chrome, Copper, Manganese, Molybdenum, Nickel, Niobium, Nitrogen, Phosphorus, Silicon, Sulfur, Titanium and Vanadium

C ≤	Si ≤	Mn ≤	P ≤	S ≤	Cr	Ni
0.12	0.75	1.00	0.06-0.15	0.035	0.30-1.25	≤0.65
Mo	Al	Cu	Nb	Ti	V	Ce
		0.25-0.55
N	Co	Pb	B	Other

S355J0WP Steel Mechanical Properties

Yield R_p0.2 (MPa)	Tensile R_m (MPa)	Impact KV/Ku (J)	Elongation A (%)	Reduction in cross section on fracture Z (%)	As-Heat-Treated Condition	Brinell hardness (HBW)
716 (≥)	775 (≥)	33	42	12	Solution and Aging, Annealing, Ausaging, Q+T,etc	322

Equivalent Grade of S355J0WP Steel

Type	Steel Grade	Standard	Country	Application
Weather Resistant Steel	Corten A	ASTM	USA	Mainly used for construction of tanks, containers, bridges, frame structures, vehicles, etc
Weather Resistant Steel	1.8945	DIN	Germany	Ideal for welding, riveting or bolting in construction applications, primarily for bridges and buildings.
Weather Resistant Steel	S355J2WP	EN10025	Europe	Mainly used for architecture, smokestacks, fabrication, freight wagons, silos, pylons etc.
Weather Resistant Steel	WR50A	BS	UK	Mainly use in applications such as steel bridges stack gas applications and in steel sculptured buildings
Weather Resistant Steel	SPA-H	JIS	Japan	Used in air preheater, economizer, railway carriage, containers production, bridge building , construction and so on.
Weather Resistant Steel	SPA-C	JIS	Japan	Used in air preheater, economizer, bridge building , construction, railway carriage, containers production and so on industry.
