1.1104 P275NL2 Pressure Vessel Steel Plate P275NL2 Low-alloy Boiler Steel

Description: P275NL2 pressure vessel steel plate is a European standard steel plate, which is a non-alloy quality steel, and the corresponding number is 1.1104. P275NL2 has high strength and good weldability and can be used to manufacture various pressure vessels, suc...

If the standard size steel materials can not meet your demands, We aslo supply P275NL2 Boiler and Pressure Vessel steel processing service. you can find one-stop solution for various customized steel processing requirements: Large vessels, structural parts, semi-products, components, manufacturing supporting ...

Processing Service: Cutting, Welding, Drilling, Rolling, Bending, Forming, Grinding, Stamping and so on machining

E-mail: [email protected]

Whatsapp: +86-15690878691

Chat Online Leave a Message

P275NL2 Boiler and Pressure Vessel steel Description

P275NL2 pressure vessel steel plate is a European standard steel plate, which is a non-alloy quality steel, and the corresponding number is 1.1104. P275NL2 has high strength and good weldability and can be used to manufacture various pressure vessels, such as storage tanks, gas tanks and boilers. P275NL2 low alloy steel is also widely used in the chemical, shipbuilding and petroleum industries.

The chemical composition of P275NL2 low alloy pressure vessel steel mainly includes carbon, silicon, manganese, phosphorus, sulfur and other elements. Among them, the content of carbon element is low, which can improve the weldability and processability of steel. The high content of silicon can improve the heat resistance and corrosion resistance of steel. The content of elements such as manganese, phosphorus, and sulfur also has an important impact on the performance of steel. This alloy steel is often used to make automotive parts, locks and other mechanical equipment. P275NL2 pressure vessel steel can withstand working conditions in high-temperature and high-pressure environments, and can also resist hydrogen electrical corrosion and the formation of stress corrosion cracks.

EN10028-3 P275NL2 pressure vessel steel is a low-alloy steel with excellent properties. In order to ensure the performance of the steel, strict quality control is required to ensure the correctness of chemical composition, heat treatment and processing. P275NL2 container steel complies with the EN10028 standard. The grades under the same standard include: P275NL1, P355NH, P355NL1, P355NL2, P420NH, P420NL1, P420NL2, P460NH, P460NL1, P460NL2, etc.

P275NL2 Boiler and Pressure Vessel steel Datasheet

Thickness: 6mm-300mm or as required
Width: 1500mm-4050mm or as required
Length: 3000mm-15000mm, etc
Thickness Tolerance: ±0.01mm
Technology: Cold Rolled / Hot Rolled
Inspection: The Third Party inspection can be accepted,SGS,BV

P275NL2 Boiler and Pressure Vessel steel Chemical composition

Grade	The Element Max (%)
Grade	C	Si	Mn	P	S	Ni	Cu	Nb	Ti	V	N	Mo
P275NL2	0.16	0.40	0.8-1.5	0.02	0.01	Max 0.5	0.30	0.050	0.03	0.05	0.012	0.08

P275NL2 Boiler and Pressure Vessel steel Mechanical Properties

Grade	Thickness	Yield	Tensilmie	Elongation	Impact Energy(KV J) min
Grade	mm	Min Mpa	Mpa	Min %	-20°	0°	+20°
P275NL2	≤16	275	390-510	24	65	90	100
	16> to ≤35	275	390-510	24	65	90	100
	35> to ≤50	265	390-510	24	65	90	100
	50> to ≤70	255	390-510	24	65	90	100
	70> to ≤100	235	370-490	23	65	90	100
	100> to ≤150	235	350-470	23	65	90	100
