Incoloy825 Alloy Steel Plate 825 Incoloy UNS N08825 Nickel Alloy Round Bar Tube

Incoloy825 Nickel Alloy Steel Description

The material of Incoloy825 alloy steel is a nickel-chromium-iron alloy containing elements such as copper, molybdenum and titanium. 825 Incoloy nickel alloy steel has good sealing, welding, processing performance and corrosion resistance. It can resist the erosion of many strong corrosive media, including sulfuric acid, hydrochloric acid, chloride, hydrofluoric acid, etc. In many chemical production processes, the medium contains these chemical substances, so the use of Incoloy 825 can ensure the long-term stable operation of the equipment.

Incoloy825 nickel alloy steel has high Ni content and high corrosion resistance, and has extremely high corrosion resistance to oxidizing and non-oxidizing acids, especially to sulfuric acid. In addition, it has good resistance to stress corrosion cracking, pitting and crevice corrosion. It has good mechanical properties at room temperature and high temperatures up to 550°C, can maintain good strength and hardness at high temperatures without deformation or deterioration, and can manufacture pressure vessels with temperatures up to 450°C.

Nickel Alloy 825 steel material with excellent corrosion resistance, good high temperature resistance and excellent mechanical properties. It is widely used in the fields of chemical industry, petrochemical industry, marine engineering and nuclear industry, etc., which can ensure the long-term operation stability and safety of the equipment. Due to its corrosion resistance and high temperature resistance, Incoloy 825 steel pipe is also widely used in some special environments, such as industrial equipment in strong acid environments such as sulfuric acid, nitric acid, and hydrochloric acid.

Incoloy825 Nickel Alloy Steel Datasheet

Shape: Coil, Strip, Foil, Ribbon Wire, Profile, Round, Flat, Square

Specification:
Wire: 0.01-10mm
Strip: 0.05*5.0-5.0*250mm
Bar: φ4-600mm, Length 2000-12000mm
Pipe: φ6-273mm, δ1-30mm, Length 1000-12000mm
Sheet: δ 0.8-36mm, Width 650-2000mm, Length 800-4500mm

Standard: GB,AISI,ASTM,DIN,EN,SUS,UNS etc

Inspection:  ISO,SGS,BV and so on.

Incoloy825 Nickel Alloy Steel Chemical composition

Incoloy825 Nickel Alloy Steel Mechanical Properties

825 Incoloy Physical Properties

Density
0.294 lbs/in³
8.14 g/cm³

Specific Heat
0.105 BTU/lb-°F
440 J/kg-°K

Modulus of Elasticity
28.3 psi x 10⁶ (100°F)
196 MPa (38°C)

Magnetic Permeability: 1.005 Oersted (μ at 200H)

Thermal Conductivity
76.8 BTU/hr/ft²/ft-°F (78°F)
11.3 W/m-°K (26°C)

Melting Range
2500 – 2550°F
1370 – 1400°C

Electrical Resistivity
678 Ohm circ mil/ft (78°F)
1.13 μ cm (26°C)

Linear Coefficient of Thermal Expansion
7.8 x 10-⁶ in / in°F (200°F)
4 m / m°C (93°F)

Equivalent Grade of Incoloy825 Nickel Alloy Steel
