ASTM A514 Grade H carbon and low-alloy steel, A514 Gr.H structural steel

Description: ASTM A514 Grade H carbon steel is an alloy structural steel plate, and it is also a steel plate for marine engineering equipment. A514 GrH low alloy high strength steel has high-quality properties such as high strength, high toughness, corrosion resistanc...

If the standard size steel materials can not meet your demands, We aslo supply A514 Gr.H Steel processing service. you can find one-stop solution for various customized steel processing requirements: Large vessels, structural parts, semi-products, components, manufacturing supporting ...

Processing Service: Cutting, Welding, Drilling, Rolling, Bending, Forming, Grinding, Stamping and so on machining

E-mail: [email protected]

Whatsapp: +86-15690878691

Chat Online Leave a Message

A514 Gr.H Steel Description

ASTM A514 Grade H carbon steel is an alloy structural steel plate, and it is also a steel plate for marine engineering equipment. A514 GrH low alloy high strength steel has high-quality properties such as high strength, high toughness, corrosion resistance, oxidation resistance, wear resistance, fatigue resistance, and easy welding and processing. The implementation standard of A514 GrH steel plate is the special technical condition of ASTM. A514 GrH steel plate is delivered in quenched and tempered state by default, so the permeability of A514 GrH steel plate is very good.

A514 GrH low alloy high strength steel is a structural steel plate that is often used in the field of machinery and equipment, such as large forklifts, railway equipment, on-board machinery, coal mining machinery, large forklifts, iron anchors and other equipment. A514 GrH steel plate is also widely used in the marine engineering manufacturing industry, such as; offshore platform construction, marine channel racks, derricks, leg piles, etc.

A514 Gr.H Steel Datasheet

Grade	A514 Grade H carbon and low-alloy steel, A514 Gr.H structural steel
Standard	ASTM A514/A514M
Size	Length: 1m-12m, or as required
	Width: 0.6m-3m, or as required
	Thickness: 0.1mm-300mm, or as required
Surface	Clean, blasting and painting according to customer requirement.
Application	There are many uses and a large amount. It is mainly used in railways, bridges, and various construction projects to manufacture.Boiler plate, pressure vessel plate,Shipbuilding steel plate,Agricultural machinery steel plate
Certificates	ROHS,CE,ISO, SGS, BV.
Package	Standard export package, or as required.
Price term	FOB, CIF, CFR, CNF, Ex-work
Payment	T/T, L/C, Western Union, etc.
Delivery time	Within 7-15 workdays after receiving deposit or L/C
Container size	20ft GP: 5898mm(Length)x2352mm(Width)x2393mm(High) 24-26CBM
	40ft GP: 12032mm(Length)x2352mm(Width)x2393mm(High) 54CBM
	40ft HC: 12032mm(Length)x2352mm(Width)x2698mm(High) 68CBM

A514 Gr.H Steel Chemical composition

C	Mn	P	S	Si	Ni	Cr	Mo	V	Ti	Zr	Cu	B	Nb
0.12-0.21	0.95-1.30	0.035	0.035	0.20-0.35	0.30-0.70	0.40-0.65	0.20-0.30	0.03-0.08	-	-	-	0.001-0.005	-

A514 Gr.H Steel Mechanical Properties

Grade	A514 Grade H Mechanical Property
Grade	Thickness	Yield	Tensile	Elongation
A514 grade H	mm	Min Mpa	Mpa	Min %
	20	690	760-895	18
	20-65	690	760-895	18
	65-150	620	690-895	18

Equivalent Grade of A514 Gr.H Steel

Steel Grade	Standard	Country	Application
QStE 690 TM	SEW 092		Mainly used for large-scale engineering structures and lightweight structures that require high strength and large loads.
S700MC	EN 10149-2	Europen	Mainly used for large-scale engineering structures and lightweight structures that require high strength and large loads.
E690D	NFA 36-231	France	Mainly use in applications such as steel bridges stack gas applications and in steel sculptured buildings
