ASTM A514 Grade F carbon low alloy steel, A514 Gr.F high-strength steel

Description: A514 Gr.F carbon and low alloy steel is a quenched and tempered high-strength weldable steel plate under the ASTM standard. The hardness of A514Gr.F steel is between 235-290, the yield is greater than 630MPa, and the tensile strength is above 700MPa....

If the standard size steel materials can not meet your demands, We aslo supply A514 Gr.F Steel processing service. you can find one-stop solution for various customized steel processing requirements: Large vessels, structural parts, semi-products, components, manufacturing supporting ...

Processing Service: Cutting, Welding, Drilling, Rolling, Bending, Forming, Grinding, Stamping and so on machining

E-mail: [email protected]

Whatsapp: +86-15690878691

Chat Online Leave a Message

A514 Gr.F Steel Description

A514 Gr.F carbon and low alloy steel is a quenched and tempered high-strength weldable steel plate under the ASTM standard. The hardness of A514Gr.F steel is between 235-290, the yield is greater than 630MPa, and the tensile strength is above 700MPa. This kind of steel plate is a little more difficult to process. The amount of A514Gr.F used in China is not considerable, but it is manufactured in factories in the United States. , General construction and various construction machinery, such as drilling rigs, electric shovels, electric wheel dump trucks, mining vehicles, excavators, loaders, bulldozers, various cranes, coal mine hydraulic supports and other mechanical equipment for mining and various engineering construction and other structural parts accounted for a large proportion.

ASTM A514 GradeF low alloy steel has high strength, good fatigue resistance, high toughness and low brittle transition temperature, good cold forming performance and welding performance, good corrosion resistance and certain wear resistance.

A514 Gr.F Steel Datasheet

Steel Grade	A514 Grade F Steel
Standard	ASTM A514/A514M
Thickness	0.15mm-300mm
Width	500-2250mm
Length	1000mm-12000mm or according to customer's special request
Tolerance	Thickness: +/-0.02mm, Width:+/-2mm
MOQ	2 Tons
Application	1.Automobile, Bridges, Buildings. 2.Machinery, Pressure vessel industries. 3.Ship building, Engineering construction. 4.Mechanical manufacturing, Pavement slab, ect.
Package	Bundle with steel strip,Container shipping
Capacity	200000 tons /month
Mill MTC	can be supplied before shipment
Inspection	The Third Party inspection can be accepted,SGS,BV

A514 Gr.F Steel Chemical composition

C	Mn	P	S	SI	Cr	Mo	B	Ni	Cu
0.12-0.20	0.6-1.0	0.035	0.035	0.15-0.35	0.40-0.65	0.4-0.6	0.001-0.005	0.7-0.1	0.15-0.5

A514 Gr.F Steel Mechanical Properties

Grade	A514 Grade F Mechanical Property
Grade	Thickness	Yield	Tensile	Elongation
A514 grade F	mm	Min Mpa	Mpa	Min %
	20	690	760-895	18
	20-65	690	760-895	18
	65-150	620	690-895	18

Equivalent Grade of A514 Gr.F Steel

Steel Grade	Standard	Country	Application
QStE 690 TM	SEW 092		Mainly used for large-scale engineering structures and lightweight structures that require high strength and large loads.
S700MC	EN 10149-2	Europen	Mainly used for large-scale engineering structures and lightweight structures that require high strength and large loads.
E690D	NFA 36-231	France	Mainly use in applications such as steel bridges stack gas applications and in steel sculptured buildings
